  • Split-core CT clamp 13 mm with 3.5 mm jack leadglbRotate in 3D
    Split-core CT clamp 13 mm with 3.5 mm jack lead

    Split-core current transformer clamp with a 13 mm aperture, about 40 x 44 x 22 mm, lying on its back: black moulded fixed half (secondary coil inside) and hinged half swung open about 62 degrees on a steel pin hinge so both grey ferrite core halves show at the split, latch tab and catch ridge, and the lead leaving a boss and strain relief, laid on the floor and ending in a 3.5 mm stereo jack plug (tip, ring and sleeve contacts with insulating rings). Generic, no logos, silkscreen text or chip markings. Overall 96.3 x 112.2 x 22.0 mm. Overall 96 x 112 x 22 mm. Nominal size: 96.28 x 112.17 x 22.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Precision current and power monitor breakout 20 x 15 mm, I2CglbRotate in 3D
    Precision current and power monitor breakout 20 x 15 mm, I2C

    Precision bidirectional current / power monitor breakout 20 x 15 mm: blue PCB with the MSOP-10 monitor IC, a 2512 0.1 ohm current shunt resistor between two wire holes (IN+, IN-) at the front corners, passives and a 6-pin 2.54 mm header soldered underneath at the back; standing on the header pins. Generic, no logos, silkscreen text or chip markings. Overall 20.0 x 15.0 x 11.5 mm. Overall 20 x 15 x 12 mm. Nominal size: 20.00 x 15.00 x 11.50 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • DC voltage divider sensor module 0-25 V, 27 x 14 mmglbRotate in 3D
    DC voltage divider sensor module 0-25 V, 27 x 14 mm

    DC voltage sensor module 27 x 14 mm (0-25 V, 5 : 1 resistive divider): red PCB with two 0805 divider resistors, a blue 2-pin 5.08 mm screw terminal for the measured voltage, one 3.2 mm mounting hole and a 3-pin 2.54 mm header (S, +, -) soldered underneath; standing on the header pins. Generic, no logos, silkscreen text or chip markings. Overall 27.0 x 14.0 x 20.1 mm. Overall 27 x 14 x 20 mm. Nominal size: 27.00 x 14.00 x 20.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Hall-effect current sensor module 5 A, 31 x 13 mmglbRotate in 3D
    Hall-effect current sensor module 5 A, 31 x 13 mm

    Hall-effect current sensor module 31 x 13 mm: red PCB with the SOIC-8 Hall sensor IC in the current path, a blue 2-pin 5.08 mm screw terminal (rising clamps and captive screws) at one end, filter capacitors, resistor and power LED, and a 3-pin 2.54 mm header (VCC, OUT, GND) soldered underneath at the other end; standing on the header pins (5 A range version: the same board as the 20 A and 30 A versions). Generic, no logos, silkscreen text or chip markings. Overall 31.0 x 13.0 x 20.1 mm. Overall 31 x 13 x 20 mm. Nominal size: 31.00 x 13.00 x 20.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Hall-effect current sensor module 30 A, 31 x 13 mmglbRotate in 3D
    Hall-effect current sensor module 30 A, 31 x 13 mm

    Hall-effect current sensor module 31 x 13 mm: red PCB with the SOIC-8 Hall sensor IC in the current path, a blue 2-pin 5.08 mm screw terminal (rising clamps and captive screws) at one end, filter capacitors, resistor and power LED, and a 3-pin 2.54 mm header (VCC, OUT, GND) soldered underneath at the other end; standing on the header pins (30 A range version: the same board as the 5 A and 20 A versions). Generic, no logos, silkscreen text or chip markings. Overall 31.0 x 13.0 x 20.1 mm. Overall 31 x 13 x 20 mm. Nominal size: 31.00 x 13.00 x 20.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Hall-effect current sensor module 20 A, 31 x 13 mmglbRotate in 3D
    Hall-effect current sensor module 20 A, 31 x 13 mm

    Hall-effect current sensor module 31 x 13 mm: red PCB with the SOIC-8 Hall sensor IC in the current path, a blue 2-pin 5.08 mm screw terminal (rising clamps and captive screws) at one end, filter capacitors, resistor and power LED, and a 3-pin 2.54 mm header (VCC, OUT, GND) soldered underneath at the other end; standing on the header pins (20 A range version: the same board as the 5 A and 30 A versions). Generic, no logos, silkscreen text or chip markings. Overall 31.0 x 13.0 x 20.1 mm. Overall 31 x 13 x 20 mm. Nominal size: 31.00 x 13.00 x 20.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • High-side current and power monitor breakout 25 x 22 mm, I2CglbRotate in 3D
    High-side current and power monitor breakout 25 x 22 mm, I2C

    High-side current / power monitor breakout 25 x 22 mm: purple PCB with the SOIC-8 monitor IC, a 2512 0.1 ohm current shunt resistor, a green 2-pin 3.5 mm terminal block for VIN+ / VIN- facing the front, address and filter passives, power LED, two mounting holes and a 6-pin 2.54 mm header soldered underneath; standing on the header pins. Generic, no logos, silkscreen text or chip markings. Overall 25.0 x 22.0 x 18.6 mm. Overall 25 x 22 x 19 mm. Nominal size: 25.00 x 22.00 x 18.60 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • AC voltage sensor module with transformer, 50 x 19 mmglbRotate in 3D
    AC voltage sensor module with transformer, 50 x 19 mm

    AC voltage sensor module 50 x 19 mm: blue PCB with a small encapsulated voltage transformer, a SOIC-8 dual op-amp, a blue multi-turn trimmer with brass adjusting screw, passives and power LED, a blue 2-pin 5.08 mm screw terminal for the AC input at one end, two mounting holes and a 4-pin 2.54 mm header (VCC, OUT, GND, GND) soldered underneath at the other end; standing on the header pins. Generic, no logos, silkscreen text or chip markings. Overall 50.0 x 19.0 x 25.1 mm. Overall 50 x 19 x 25 mm. Nominal size: 50.00 x 19.00 x 25.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • TP&N switch-fuse 63 A with fuse carriers, door openglbRotate in 3D
    TP&N switch-fuse 63 A with fuse carriers, door open

    Generic TP&N switch-fuse 63 A in a light grey sheet-steel box about 240 x 340 x 150 mm with the hinged door shown open: three black fuse carriers holding white ceramic cartridge fuses with brass end caps on black fuse bases, a blue solid neutral link, the switch mechanism block with incoming terminal screws, a red side operating handle on the square mechanism spindle through the right wall (ON), quarter-turn door lock, two M32 glands below and one above. Generic, no logos, rating labels or text. Overall 336 x 398 x 394 mm. Overall 336 x 398 x 394 mm. Nominal size: 335.54 x 398.47 x 394.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • TPN switch disconnector 63 A in steel enclosure, rotary handleglbRotate in 3D
    TPN switch disconnector 63 A in steel enclosure, rotary handle

    Generic TPN (3P+N) switch disconnector 63 A in a light grey sheet-steel enclosure about 200 x 300 x 150 mm: screwed front cover with four screws, black rotary handle on a dark grey escutcheon fitted on the square switch spindle (shown ON), blank label plate, two M32 nylon cable glands with locknuts through the bottom wall, and inside a galvanised mounting plate with the switch body. Generic, no logos, rating labels or text. Overall 204 x 170 x 329 mm. Overall 204 x 170 x 329 mm. Nominal size: 204.00 x 170.50 x 329.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • TPN switch disconnector 100 A in steel enclosure, rotary handleglbRotate in 3D
    TPN switch disconnector 100 A in steel enclosure, rotary handle

    Generic TPN (3P+N) switch disconnector 100 A in a light grey sheet-steel enclosure about 260 x 380 x 180 mm: screwed front cover, black rotary handle on a dark grey escutcheon on the square switch spindle (shown ON), blank label plate, two M40 cable glands with locknuts through the bottom wall, mounting plate and switch body inside. Generic, no logos, rating labels or text. Overall 264 x 200 x 412 mm. Overall 264 x 200 x 412 mm. Nominal size: 264.00 x 200.50 x 412.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • 6-way TPN distribution board with incomer isolator and MCBs, door openglbRotate in 3D
    6-way TPN distribution board with incomer isolator and MCBs, door open

    Generic 6-way TPN distribution board in a light grey sheet-steel cabinet about 360 x 520 x 120 mm with the hinged door open: a 125 A 4P main switch disconnector (red toggle) as incomer and six three-pole MCBs (black toggles with tie bars) on two DIN rails fed by insulated pin comb busbars, a brass neutral bar on blue insulators and an earth bar on green standoffs, glands top and bottom, blank label plate on the door. Generic, no logos, rating labels or text. Overall 500 x 472 x 577 mm. Overall 500 x 472 x 577 mm. Nominal size: 500.04 x 472.11 x 577.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Enclosed rotary isolator IP65 63 A 4-pole, padlockable, padlocked OFFglbRotate in 3D
    Enclosed rotary isolator IP65 63 A 4-pole, padlockable, padlocked OFF

    Generic enclosed rotary isolator 63 A 4-pole, IP65, padlockable: light grey moulded box about 150 x 190 x 125 mm with a screwed lid, red rotary handle on a yellow plate turned to OFF and locked off with a padlock whose shackle passes through the handle and a steel hasp lug, two M32 glands below. Generic, no logos, rating labels or text. Overall 156 x 144 x 217 mm. Overall 156 x 144 x 217 mm. Nominal size: 156.00 x 144.00 x 217.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Enclosed rotary isolator IP65 20 A 4-poleglbRotate in 3D
    Enclosed rotary isolator IP65 20 A 4-pole

    Generic enclosed rotary isolator 20 A 4-pole, IP65: light grey moulded box about 85 x 125 x 94 mm (deeper than the 3-pole for the fourth contact deck), screwed lid, red rotary handle on a yellow plate on the switch spindle (ON), two M20 cable glands through the bottom. Generic, no logos, rating labels or text. Overall 85.0 x 113.0 x 146.0 mm. Overall 85 x 113 x 146 mm. Nominal size: 85.00 x 113.00 x 146.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Enclosed rotary isolator IP65 20 A 3-poleglbRotate in 3D
    Enclosed rotary isolator IP65 20 A 3-pole

    Generic enclosed rotary isolator 20 A 3-pole, IP65: light grey moulded box about 85 x 125 x 80 mm with rounded corners and a screwed lid (four screws), red rotary handle on a yellow plate fitted on the switch spindle (shown ON), two M20 cable glands through the bottom. Generic, no logos, rating labels or text. Overall 85.0 x 99.0 x 146.0 mm. Overall 85 x 99 x 146 mm. Nominal size: 85.00 x 99.00 x 146.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Main switch disconnector 125 A 4P for distribution boards, DIN railglbRotate in 3D
    Main switch disconnector 125 A 4P for distribution boards, DIN rail

    Generic 125 A 4-pole main switch disconnector for distribution boards: four 17.5 mm modules, light grey housing with a large red toggle (ON), blank label plate, large terminal screws and wire entries top and bottom, clipped on a 35 mm DIN rail. Generic, no logos, rating labels or text. Overall 114.0 x 84.5 x 96.0 mm. Overall 114 x 84 x 96 mm. Nominal size: 114.00 x 84.45 x 96.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • DIN-rail modular isolator 3P+N 63 A, 70 mmglbRotate in 3D
    DIN-rail modular isolator 3P+N 63 A, 70 mm

    Generic 3P+N (TPN) DIN-rail modular isolator 63 A, four 17.5 mm modules: light grey housing, one wide dark grey toggle across all four poles (ON), blank label plate, eight terminal screws with wire entries top and bottom, clipped on a 35 mm DIN rail. Generic, no logos, rating labels or text. Overall 110.0 x 81.5 x 96.0 mm. Overall 110 x 81 x 96 mm. Nominal size: 110.00 x 81.47 x 96.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • DIN-rail modular isolator 2P 63 A, 35 mmglbRotate in 3D
    DIN-rail modular isolator 2P 63 A, 35 mm

    Generic double-pole DIN-rail modular isolator 63 A, two 17.5 mm modules: light grey housing, one wide dark grey toggle across both poles (ON), blank label plate, four terminal screws with wire entries, clipped on a short 35 mm DIN rail. Generic, no logos, rating labels or text. Overall 75.0 x 81.5 x 96.0 mm. Overall 75 x 81 x 96 mm. Nominal size: 75.00 x 81.47 x 96.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • DIN-rail modular isolator 1P 63 A, 17.5 mmglbRotate in 3D
    DIN-rail modular isolator 1P 63 A, 17.5 mm

    Generic single-pole DIN-rail modular isolator 63 A, one 17.5 mm module: light grey housing with the 45 mm front window, dark grey toggle (ON), blank label plate, terminal screws on both shoulders with wire entries top and bottom, rail hooks and a slider clip, clipped on a short slotted 35 mm DIN rail. Generic, no logos, rating labels or text. Overall 57.5 x 81.5 x 96.0 mm. Overall 58 x 81 x 96 mm. Nominal size: 57.50 x 81.47 x 96.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Manual changeover switch 63 A 4-pole (I-0-II) in enclosureglbRotate in 3D
    Manual changeover switch 63 A 4-pole (I-0-II) in enclosure

    Generic manual changeover switch 63 A 4-pole (I-0-II) in a light grey sheet-steel enclosure about 220 x 320 x 160 mm: screwed cover, black rotary handle on a dark grey plate in the 0 position, position marks as plain raised bar (I), ring (0) and double bar (II), blank label plate, three M32 glands below (supply I, supply II, load), switch body inside. Generic, no logos, rating labels or text. Overall 224 x 181 x 349 mm. Overall 224 x 181 x 349 mm. Nominal size: 224.00 x 180.50 x 349.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Solar panel 20 W 12 V, 430 x 350 mm, aluminium frameglbRotate in 3D
    Solar panel 20 W 12 V, 430 x 350 mm, aluminium frame

    Small 20 W 12 V framed solar panel, 430 x 350 x 25 mm: anodised aluminium frame with mitred corners, 36 cut monocrystalline cell pieces (4 x 9) under alpha-blended front glass, busbars along each cell column and bus ribbons at the column ends, white backsheet; on the back a compact junction box with red and black leads ending in tinned tips and mounting-slot marks on the frame flange. Generic, no logos or label text. Overall 350 x 25 x 430 mm. Overall 350 x 25 x 430 mm. Nominal size: 350.00 x 25.31 x 430.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Solar panel 10 W 12 V, 350 x 280 mm, aluminium frameglbRotate in 3D
    Solar panel 10 W 12 V, 350 x 280 mm, aluminium frame

    Small 10 W 12 V framed solar panel, 350 x 280 x 18 mm: anodised aluminium frame with mitred corners, 36 cut monocrystalline cell pieces (4 x 9) under alpha-blended front glass, busbars along each cell column and bus ribbons at the column ends, white backsheet; on the back a compact junction box with red and black leads ending in tinned tips and mounting-slot marks on the frame flange. Generic, no logos or label text. Overall 280 x 18 x 350 mm. Overall 280 x 18 x 350 mm. Nominal size: 280.00 x 18.31 x 350.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • Bifacial glass-glass solar module, 144 half cells, 2278 x 1134 x 30 mmglbRotate in 3D
    Bifacial glass-glass solar module, 144 half cells, 2278 x 1134 x 30 mm

    Bifacial glass-glass module 2278 x 1134 x 30 mm: anodised aluminium frame with mitred corners, 144 half-cut cells (6 x 24, two halves) with busbars on both faces under alpha-blended front glass, busbars along each cell column and bus ribbons at the column ends, a transparent rear glass so light passes between the cells; on the back three split junction boxes on the rear glass with cables to in-line connectors and mounting-slot marks on the frame flange. Generic, no logos or label text. Overall 1134 x 30 x 2278 mm. Overall 1.1 x 0 x 2.3 m. Nominal size: 1134.00 x 30.31 x 2278.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

  • 72-cell monocrystalline solar module, 1956 x 992 x 40 mmglbRotate in 3D
    72-cell monocrystalline solar module, 1956 x 992 x 40 mm

    72-cell monocrystalline commercial module 1956 x 992 x 40 mm: anodised aluminium frame with mitred corners, 72 near-black pseudo-square cells (6 x 12) under alpha-blended front glass, busbars along each cell column and bus ribbons at the column ends, white backsheet showing between the cells; on the back a junction box with two solar cables lying on the backsheet to in-line connectors and mounting-slot marks on the frame flange. Generic, no logos or label text. Overall 992 x 40 x 1956 mm. Overall 992 x 40 x 1956 mm. Nominal size: 992.00 x 40.31 x 1956.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
