Free Construction Details (DWG)

Construction details showing how things are built: footings, walls, railings, gates, drainage and site furniture. Every file here is public domain: open it in your browser, then download it and use it for anything.

1853 drawings · DWG, DXF, PDF, SVG, DWF and more · public domain

632 drawings in Construction details · Clear all

  • Entrance sign structure (USFS IB3)dwfOpen the drawing
    Entrance sign structure (USFS IB3)

    Elevation, section and footing details of a timber entrance sign. USDA Forest Service standard drawing plotted to a DWF sheet (ANSI B).

    28 KB · by USDA Forest ServiceDetails & download
  • Picnic shelter (USFS ASP5)dwfOpen the drawing
    Picnic shelter (USFS ASP5)

    Section and details of an open timber picnic shelter. USDA Forest Service standard drawing plotted to a DWF sheet (ANSI B).

    29 KB · by USDA Forest ServiceDetails & download
  • Comfort station, Gold Beach (USFS AS110602)dwfOpen the drawing
    Comfort station, Gold Beach (USFS AS110602)

    Plans, elevations and details of a restroom building. USDA Forest Service standard drawing plotted to a DWF sheet (ANSI B).

    95 KB · by USDA Forest ServiceDetails & download
  • RFI: luminaire and duct clash (Word 97-2003)docOpen the drawing
    RFI: luminaire and duct clash (Word 97-2003)

    Construction request for information about a ceiling luminaire clashing with a supply duct, with a section sketch and options.

  • Straight reinforced concrete stair structural detaildxfOpen the drawing
    Straight reinforced concrete stair structural detail

    Straight reinforced concrete stair structural detail (detalle estructural escalera de un tramo recto): one flight of 18 risers of 166.7 mm and 17 goings of 270 mm (4590 mm) over 3000 mm, 1400 mm wide with a 200 mm waist, spanning from a 600 x 500 ground beam to a 250 x 450 landing beam; landing 1410 mm long at +3.000, overall 6000 x 1400 x 3000 mm, headroom 2013 mm below the stairwell trimmer. Section A-A, stair plan, ground beam and landing beam details and cross-section B-B with 9 main bars of 12 mm at 150. A3 sheet; DXF 1:1 mm, section and plan 1:50, details 1:20. Nominal size: 6000 x 1400 x 3000 mm (flight 4590 + landing 1410). DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Stair landing reinforcement detaildxfOpen the drawing
    Stair landing reinforcement detail

    Stair landing reinforcement detail for the dog-leg half landing (DRG 2104-03): 2800 x 1400 x 180 mm at +1.500, spanning 2800 between the side walls with 150 mm bearings. Reinforcement plan with representative bars and range lines for L1 (9 bars of 12 mm at 150, bottom), L2, L3 (10 mm at 200 top over the walls, 750 long), L4 and the L5 edge bars, the flight bars entering the free edge, section C-C across the span, section D-D at the flight 2 junction and a bar schedule with lengths. A3 sheet; DXF 1:1 mm, plan and sections 1:20. Nominal size: 2800 x 1400 x 180 mm landing slab. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Dog-leg reinforced concrete stair structural detaildxfOpen the drawing
    Dog-leg reinforced concrete stair structural detail

    Dog-leg reinforced concrete stair structural detail (detalle estructural escalera de ida y vuelta): 18 risers of 166.7 mm and 2 x 8 goings of 280 mm over 3000 mm, flights 1300 mm wide with a 200 mm well in a 6000 x 2800 mm stair core, half landing 1400 x 2800 x 180 mm at +1.500, 180 mm waist and 25 mm nominal cover. Section A-A through flight 1 with bars 01 to 05 (01 and 02 crossing at the landing knee), ground beam GB 500 x 500 and landing beam LB 250 x 450, headroom 2383 mm, stair plan and a knee detail. A3 sheet; DXF 1:1 mm, section 1:25, plan 1:50, knee 1:10. Nominal size: 6000 x 2800 x 3000 mm stair core (half landing 1400 x 2800 x 180 mm). DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Two-bay slab formwork plan / plan de coffragedxfOpen the drawing
    Two-bay slab formwork plan / plan de coffrage

    Plan de coffrage (slab formwork plan) for a two-bay reinforced concrete frame on a 12000 x 6000 mm grid (grids A to C and 1 to 2 at 6000): 150 mm slab at +3.500 with a 12300 x 6300 mm outline, 300 x 600 frame beams, 300 x 500 edge beams, a 250 x 500 secondary beam, six 300 x 300 columns and an 800 x 600 opening, with an element schedule. Typical falsework bay with 21 mm form-ply on H20 secondary beams at 475 and primary beams 1825 apart on floor props at 1000, section A-A and a decking detail at a prop head. A3 sheet; DXF 1:1 mm, plan 1:75, bay 1:100, section 1:75, detail 1:20. Nominal size: 12000 x 6000 mm grid, slab 12300 x 6300 x 150 mm at +3.500. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Shiplap timber cladding detaildxfOpen the drawing
    Shiplap timber cladding detail

    Shiplap timber cladding detail (wooden cladding): horizontal rebated 22 x 145 mm shiplap boards at 133 mm cover with a 12 mm lap and 2 mm gap on 38 x 50 mm vertical battens at 600 mm, over a timber frame wall with 38 x 140 studs, 9 mm OSB and a breather membrane; 246.5 mm build-up. Elevation of a 1200 x 2400 mm panel, horizontal section, base and head sections with insect mesh, a 150 mm ground clearance and a 20 mm vent, and a joint detail with the fixings. A3 sheet; DXF 1:1 mm, elevation 1:20, sections 1:5 and 1:10, joint 1:2. Nominal size: 1200 x 246.5 x 2400 mm (panel width x build-up x height). DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Open-joint timber cladding detaildxfOpen the drawing
    Open-joint timber cladding detail

    Open-joint timber cladding detail (wooden cladding): horizontal 22 x 95 mm boards with 10 mm open joints and weathered top edges on black 38 x 50 mm battens with EPDM strips at 600 mm, over a timber frame wall with 38 x 140 studs, 9 mm OSB and a black UV-stable breather membrane; 246.5 mm build-up. Elevation of a 1200 x 2400 mm panel, horizontal section, base and head sections with insect mesh, a 150 mm ground clearance and a 20 mm vent, and a joint detail with the fixings. A3 sheet; DXF 1:1 mm, elevation 1:20, sections 1:5 and 1:10, joint 1:2. Nominal size: 1200 x 246.5 x 2400 mm (panel width x build-up x height). DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Board-on-batten timber cladding detaildxfOpen the drawing
    Board-on-batten timber cladding detail

    Board-on-batten timber cladding detail (wooden cladding): vertical 22 x 150 mm boards with 10 mm gaps and 22 x 50 mm cover battens on 38 x 50 mm battens and 25 x 50 mm counter battens at 600 mm, over a timber frame wall with 38 x 140 studs, 9 mm OSB and a breather membrane; 293.5 mm build-up. Elevation of a 1200 x 2400 mm panel, horizontal section, base and head sections with insect mesh, a 150 mm ground clearance and a 20 mm vent, and a joint detail with the fixings. A3 sheet; DXF 1:1 mm, elevation 1:20, sections 1:5 and 1:10, joint 1:2. Nominal size: 1200 x 293.5 x 2400 mm (panel width x build-up x height). DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Beam and column formwork detailsdxfOpen the drawing
    Beam and column formwork details

    Beam and column formwork details for column C1 and beam B1 of the two-bay frame (DRG 2104-01): elevation of the 300 x 300 column form 2900 high to the beam soffit on a 75 mm kicker, with 21 mm form-ply, 63 x 100 studs, seven steel column clamps spaced from 250 at the base to 500, a cleanout panel and push-pull props; plan section through a clamp (900 arms, 20 x 20 chamfer fillets); section of the 300 x 600 beam form with a 21 mm soffit on two 63 x 100 runners, a 75 x 150 headtree bearer, side forms with 50 x 100 soldiers, ledgers, kicker cleats and struts; clamp schedule. A3 sheet; DXF 1:1 mm, elevation 1:25, sections 1:20 and 1:10. Nominal size: Column form 900 x 900 x 2900 mm (clamps x clamps x height); beam form 300 x 600 mm. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Tiled wet room floor waterproofing detaildxfOpen the drawing
    Tiled wet room floor waterproofing detail

    Original tiled wet room floor waterproofing detail with a 1200 x 1200 mm shower zone, a 100 mm linear channel and a 50 mm bore outlet. The floor falls 21 mm over 1050 mm to the drain and continues flush to a 400 mm bathroom strip. Continuous membrane bonds to the drain flanges and turns into the channel. Overall 1983 x 1011 x 0 mm. Nominal size: 1200 x 1200 mm wet zone; 100 mm channel; 50 mm bore outlet. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Shower tray threshold waterproofing detaildxfOpen the drawing
    Shower tray threshold waterproofing detail

    Original shower tray threshold waterproofing detail for a 1200 x 900 mm tiled tray with a 100 mm masonry curb core. A continuous 2 mm nominal membrane wraps the inward-falling curb and joins the bathroom floor membrane; 10 mm tile and 4 mm adhesive are shown at fixed scales. Overall 1258 x 510 x 0 mm. Nominal size: 1200 x 900 mm tiled tray; 100 mm curb core; 1:50 falls. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Planter waterproofing detaildxfOpen the drawing
    Planter waterproofing detail

    Original dimensioned wet-area waterproofing study: 1500 x 1000 x 800 mm planter / 150 mm walls. Section, drainage plan and enlarged sealed junction. Overall 1680 x 1540 x 0 mm. Nominal size: 1500 x 1000 x 800 mm planter / 150 mm walls. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Below-ground tanking junction detaildxfOpen the drawing
    Below-ground tanking junction detail

    Original below-ground tanking study with a 250 mm wall, 300 mm raft and continuous 2 mm external membrane terminating 200 mm above the shown grade. Overall 3 x 3.2 x 0 m. Nominal size: 250 mm wall / 300 mm raft / 2 mm barrier. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Bath upstand waterproofing detaildxfOpen the drawing
    Bath upstand waterproofing detail

    Original 1700 x 700 mm bath upstand waterproofing study with a 35 mm formed flange, 12.5 mm supported wall lining and 50 mm membrane overlap. Overall 1559 x 1414 x 0 mm. Nominal size: 1700 x 700 mm nominal bath / 35 mm upstand. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Balcony threshold waterproofing detaildxfOpen the drawing
    Balcony threshold waterproofing detail

    Original dimensioned wet-area waterproofing study: 1800 x 1200 mm bay / 90 mm upstand / 150 mm channel. Section, drainage plan and enlarged sealed junction. Overall 1639 x 1070 x 0 mm. Nominal size: 1800 x 1200 mm bay / 90 mm upstand / 150 mm channel. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Steel to concrete anchor plate detaildxfOpen the drawing
    Steel to concrete anchor plate detail

    Original 2D 300 x 300 x 12 mm flush cast-in steel plate with four 16 mm headed studs in a 320 mm concrete wall and a 200 mm projected seat bracket. Overall 989 x 784 x 0 mm. Nominal size: 300 x 300 x 12 mm plate / 182 mm total embedment. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Steel purlin cleat detaildxfOpen the drawing
    Steel purlin cleat detail

    Original dimensioned steel connection study: 200 x 65 x 15 x 2 mm C purlin / 8 mm cleat. Connection elevation, cut section and local assembly detail. Overall 332 x 390 x 0 mm. Nominal size: 200 x 65 x 15 x 2 mm C purlin / 8 mm cleat. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Holding-down bolt detaildxfOpen the drawing
    Holding-down bolt detail

    Original 2D M20 holding-down rod with 460 mm outside embedment, 140 mm centre-to-toe hook reach, R60 centreline bend and 100 mm exposed projection through a 180 x 180 x 20 mm plate. Overall 851 x 889 x 0 mm. Nominal size: M20 / 460 mm embedded depth / 140 mm hook reach. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Steel fin plate connection detaildxfOpen the drawing
    Steel fin plate connection detail

    Original steel fin plate connection detail with a 300 x 150 mm fabricated I beam, 160 x 220 x 10 mm fin plate, six M20 bolts and a 10 mm beam-end clearance. The horizontal section shows the offset plate and 8 mm double fillet weld. Overall 779 x 894 x 0 mm. Nominal size: 300 mm beam; 160 x 220 x 10 mm fin plate; 10 mm end gap. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Column base plate with anchor bolts detaildxfOpen the drawing
    Column base plate with anchor bolts detail

    Original 2D 400 x 400 x 25 mm column base on 40 mm grout with four M24 cast-in rods on a 280 mm grid and a 600 mm square local pedestal. Overall 1256 x 1254 x 0 mm. Nominal size: 400 x 400 x 25 mm plate / M24 anchors. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.

  • Steel bracing gusset detaildxfOpen the drawing
    Steel bracing gusset detail

    Original dimensioned steel connection study: 10 mm gusset / paired 75 x 75 x 6 mm angles. Connection elevation, cut section and local assembly detail. Overall 752 x 1037 x 0 mm. Nominal size: 10 mm gusset / paired 75 x 75 x 6 mm angles. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
