Free Construction Details (DWG)
Construction details showing how things are built: footings, walls, railings, gates, drainage and site furniture. Every file here is public domain: open it in your browser, then download it and use it for anything.
1332 drawings · DWG, DXF, PDF, SVG, DWF and more · public domain
572 drawings in Construction details · Clear all
dxfOpen the drawing
Tiled wet room floor waterproofing detailOriginal tiled wet room floor waterproofing detail with a 1200 x 1200 mm shower zone, a 100 mm linear channel and a 50 mm bore outlet. The floor falls 21 mm over 1050 mm to the drain and continues flush to a 400 mm bathroom strip. Continuous membrane bonds to the drain flanges and turns into the channel. Overall 1983 x 1011 x 0 mm. Nominal size: 1200 x 1200 mm wet zone; 100 mm channel; 50 mm bore outlet. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
140 KBDetails & downloaddxfOpen the drawing
Shower tray threshold waterproofing detailOriginal shower tray threshold waterproofing detail for a 1200 x 900 mm tiled tray with a 100 mm masonry curb core. A continuous 2 mm nominal membrane wraps the inward-falling curb and joins the bathroom floor membrane; 10 mm tile and 4 mm adhesive are shown at fixed scales. Overall 1258 x 510 x 0 mm. Nominal size: 1200 x 900 mm tiled tray; 100 mm curb core; 1:50 falls. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
112 KBDetails & downloaddxfOpen the drawing
Planter waterproofing detailOriginal dimensioned wet-area waterproofing study: 1500 x 1000 x 800 mm planter / 150 mm walls. Section, drainage plan and enlarged sealed junction. Overall 1680 x 1540 x 0 mm. Nominal size: 1500 x 1000 x 800 mm planter / 150 mm walls. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
164 KBDetails & downloaddxfOpen the drawing
Below-ground tanking junction detailOriginal below-ground tanking study with a 250 mm wall, 300 mm raft and continuous 2 mm external membrane terminating 200 mm above the shown grade. Overall 3 x 3.2 x 0 m. Nominal size: 250 mm wall / 300 mm raft / 2 mm barrier. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
150 KBDetails & downloaddxfOpen the drawing
Bath upstand waterproofing detailOriginal 1700 x 700 mm bath upstand waterproofing study with a 35 mm formed flange, 12.5 mm supported wall lining and 50 mm membrane overlap. Overall 1559 x 1414 x 0 mm. Nominal size: 1700 x 700 mm nominal bath / 35 mm upstand. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
147 KBDetails & downloaddxfOpen the drawing
Balcony threshold waterproofing detailOriginal dimensioned wet-area waterproofing study: 1800 x 1200 mm bay / 90 mm upstand / 150 mm channel. Section, drainage plan and enlarged sealed junction. Overall 1639 x 1070 x 0 mm. Nominal size: 1800 x 1200 mm bay / 90 mm upstand / 150 mm channel. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
148 KBDetails & downloaddxfOpen the drawing
Steel to concrete anchor plate detailOriginal 2D 300 x 300 x 12 mm flush cast-in steel plate with four 16 mm headed studs in a 320 mm concrete wall and a 200 mm projected seat bracket. Overall 989 x 784 x 0 mm. Nominal size: 300 x 300 x 12 mm plate / 182 mm total embedment. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
111 KBDetails & downloaddxfOpen the drawing
Steel purlin cleat detailOriginal dimensioned steel connection study: 200 x 65 x 15 x 2 mm C purlin / 8 mm cleat. Connection elevation, cut section and local assembly detail. Overall 332 x 390 x 0 mm. Nominal size: 200 x 65 x 15 x 2 mm C purlin / 8 mm cleat. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
220 KBDetails & downloaddxfOpen the drawing
Holding-down bolt detailOriginal 2D M20 holding-down rod with 460 mm outside embedment, 140 mm centre-to-toe hook reach, R60 centreline bend and 100 mm exposed projection through a 180 x 180 x 20 mm plate. Overall 851 x 889 x 0 mm. Nominal size: M20 / 460 mm embedded depth / 140 mm hook reach. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
117 KBDetails & downloaddxfOpen the drawing
Steel fin plate connection detailOriginal steel fin plate connection detail with a 300 x 150 mm fabricated I beam, 160 x 220 x 10 mm fin plate, six M20 bolts and a 10 mm beam-end clearance. The horizontal section shows the offset plate and 8 mm double fillet weld. Overall 779 x 894 x 0 mm. Nominal size: 300 mm beam; 160 x 220 x 10 mm fin plate; 10 mm end gap. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
152 KBDetails & downloaddxfOpen the drawing
Column base plate with anchor bolts detailOriginal 2D 400 x 400 x 25 mm column base on 40 mm grout with four M24 cast-in rods on a 280 mm grid and a 600 mm square local pedestal. Overall 1256 x 1254 x 0 mm. Nominal size: 400 x 400 x 25 mm plate / M24 anchors. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
174 KBDetails & downloaddxfOpen the drawing
Steel bracing gusset detailOriginal dimensioned steel connection study: 10 mm gusset / paired 75 x 75 x 6 mm angles. Connection elevation, cut section and local assembly detail. Overall 752 x 1037 x 0 mm. Nominal size: 10 mm gusset / paired 75 x 75 x 6 mm angles. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
180 KBDetails & downloaddxfOpen the drawing
Steel beam splice detailOriginal bolted steel beam splice detail joining 300 x 150 mm fabricated I beams across a 10 mm gap. Symmetrical 480 x 150 x 12 mm outer flange plates and paired 440 x 200 x 8 mm web covers are shown with M20 bolts in 22 mm holes. Overall 794 x 894 x 0 mm. Nominal size: 300 mm beam; 10 mm gap; 480 mm flange and 440 mm web covers. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
265 KBDetails & downloaddxfOpen the drawing
Beam to column bolted end plate detailOriginal beam to column bolted end plate detail with a 300 x 150 mm fabricated I beam, 150 x 220 x 10 mm partial-depth plate and six M20 bolts in 22 mm holes. Three coordinated views show the 90 mm gauge and 70 mm vertical pitch. Overall 790 x 929 x 0 mm. Nominal size: 300 mm beam; 150 x 220 x 10 mm end plate; six M20 bolts. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
146 KBDetails & downloaddxfOpen the drawing
Roof verge detailOriginal roof verge detail with a 200 mm gable overhang, 22 x 180 mm bargeboard, 18 mm deck and 0.7 mm folded metal trim covering 205 mm of roof pan. Plan includes a 75 mm weather-facing cap lap. Overall 1201 x 1217 x 0 mm. Nominal size: 200 mm gable overhang; 205 mm cap cover; 170 mm downstand. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
87 KBDetails & downloaddxfOpen the drawing
Roof valley detailOriginal dimensioned roof section, drainage plan and enlarged junction: 600 mm projected valley / 200 mm open channel. Overall 1360 x 1255 x 0 mm. Nominal size: 600 mm projected valley / 200 mm open channel. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
114 KBDetails & downloaddxfOpen the drawing
Skylight curb detailOriginal fixed skylight detail with 900 x 1200 mm clear opening, 150 mm insulated curb, 234 mm curb height above the local roof finish and double 75 x 200 mm trimmers; A3 section, plan and enlarged frame seat. Overall 2.5 x 1.2 x 0 m. Nominal size: 900 x 1200 mm clear opening / 150 mm insulated curb. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
164 KBDetails & downloaddxfOpen the drawing
Roof ridge detailOriginal roof ridge detail: symmetrical 30 degree roof pitches, 600 mm folded cap, 70 mm deck ventilation opening and 50 x 255 mm ridge board. Enlarged detail shows a 5 mm weather-baffle air passage; plan gives a 75 mm cap lap. Overall 1606 x 1302 x 0 mm. Nominal size: 30 degree roof; 600 mm ridge cap; 70 mm deck opening; 75 mm cap lap. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
78 KBDetails & downloaddxfOpen the drawing
Roof penetration flashing detailOriginal dimensioned roof section, drainage plan and enlarged junction: 110 mm vent / 400 x 460 mm flashing flange. Overall 1013 x 1439 x 0 mm. Nominal size: 110 mm vent / 400 x 460 mm flashing flange. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
117 KBDetails & downloaddxfOpen the drawing
Parapet with coping roof detailOriginal 400 mm wide folded metal coping over a 200 mm parapet with 50 mm thermal wraps, 180 mm concrete roof deck and tapered warm-roof insulation; A3 section, fixing plan and enlarged coping junction. Overall 1499 x 1386 x 0 mm. Nominal size: 400 mm coping / 200 mm parapet / 180 mm deck. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
181 KBDetails & downloaddxfOpen the drawing
Green roof build-up detailOriginal extensive green-roof build-up with 120 mm substrate, 40 mm drainage layer, 6 mm protection mat and 300 mm gravel vegetation barrier above a warm roof; A3 section, access plan and 300 mm chamber with 100 mm outlet detail. Overall 1755 x 1128 x 0 mm. Nominal size: 120 mm substrate / 40 mm drainage / 300 mm gravel barrier. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
173 KBDetails & downloaddxfOpen the drawing
Flat roof upstand detailOriginal warm-roof upstand at a 200 mm solid wall with 200 mm membrane rise, 50 mm insulated backing, 75 mm counterflashing lap and 180 mm concrete deck; dimensioned A3 section, drainage plan and reglet detail. Overall 1474 x 1255 x 0 mm. Nominal size: 200 mm membrane rise / 200 mm wall / 180 mm deck. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
109 KBDetails & downloaddxfOpen the drawing
Eaves with gutter roof detailOriginal eaves with gutter roof detail: 30 degree metal roof with an 18 mm deck, 195 mm rafter, 125 mm clear gutter and 50 mm sheet projection beyond an 18 mm fascia. Roof plan shows a 75 mm outlet and gutter brackets. Overall 1520 x 1647 x 0 mm. Nominal size: 30 degree roof; 125 mm gutter; 50 mm sheet projection; 195 mm rafter. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
218 KBDetails & downloaddxfOpen the drawing
Dormer cheek roof detailOriginal dimensioned roof section, drainage plan and enlarged junction: 140 mm cheek / 100 x 100 mm soaker. Overall 1172 x 1649 x 0 mm. Nominal size: 140 mm cheek / 100 x 100 mm soaker. DXF drawing at 1:1 in millimeters with named layers; opens in AutoCAD, LibreCAD, Revit and the viewer. Export to DWG, PDF, SVG and other formats from the viewer. Drawn at nominal real-world dimensions for layout and documentation; verify against local codes and the actual product before construction. Original Innerscene model, released CC0.
146 KBDetails & download
