Screw-mounted under-desk hook
3D model · STL · 116 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Screw-mounted under-desk hook, modeled from published dimensions. Overall 60 x 44 x 63 mm. Key dimensions: plate 60 x 44 x 7; mount hole diameter 4.5 mm; mount hole spacing 32 mm; hook clear width 36 mm; hook depth 24 mm. Original geometry modeled from scratch in tools/cad_print_designs.py. Closed solid meshes checked digitally. Physical printing, strength and printer-specific tolerances have not been tested. Mounting screws are not included. Countersunk holes sit to either side of the hook, with a clear vertical path for a screwdriver. No load rating has been established. Print on a side face for a broad contact area. Watertight STL mesh in millimeters, ready to slice; printed performance is untested. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: under-desk-hook.stl · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
