80 x 50 x 25 mm project box - lid aside
3D model · STL · 441 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
80 x 50 x 25 mm project box - lid aside, modeled from published dimensions. Overall 172 x 50 x 22.5 mm. Key dimensions: wall 2.5 mm; lip clearance each side 0.2 mm; lid screw clearance 2.8 mm; boss pilot 2.2 mm; display open true. Original dimensioned enclosure with four blind pilot bosses and a recessed locating lid. Selected 2.5 mm wall, 0.2 mm lip clearance per side, 2.8 mm lid holes and 2.2 mm pilot bores. No screws, sealing gasket, ingress/flame rating or production shrinkage allowance. Open version places the lid beside the box for inspection. Watertight STL mesh in millimeters, ready to slice; printed performance is untested. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
