NEMA 23 stepper motor 23HS22-2804S
3D model · STEP · 310 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
NEMA 23 stepper motor 23HS22-2804S, modeled from published dimensions. Overall 57.3 x 59.3 x 77 mm. Key dimensions: drawing reference 23HS22-2804S; body width max 57.3 mm; body length max 56 mm; mount hole spacing XY 47.1 mm; mount hole diameter 5.2 mm; mount hole type 5.2 mm through clearance; shaft diameter 6.4 mm; shaft projection from mount face 21 mm; shaft flat dimension 5.9 mm; shaft flat length 15 mm; locating boss diameter 38.1 mm; locating boss height 1.6 mm. Mounting pattern, nominal shaft/flat/boss geometry and maximum body envelope follow the cited manufacturer drawing. Z=0 is the mounting face. Internal motor construction, long cable, markings and connector contacts are omitted. Case seams, fastener details and connector housing are representative. Mounting taps are shown as nominal cylindrical envelopes. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: nema23-23hs22-2804s.step · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
