Ball bearing 6204 (sealed)
3D model · STEP · 79 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Ball bearing 6204 (sealed), modeled from published dimensions. Overall 47 x 47 x 14 mm. Key dimensions: bore 20 mm; outside diameter 47 mm; width 14 mm; configuration Recessed dual seals; simplified internal envelope. Bore, outside diameter and width match the cited manufacturer dimensional table. Races and seal profiles are representative. Balls, cage, grease and internal clearances are omitted; this is an installation-envelope model. No load or speed rating is implied by this generic geometry. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: bearing-6204.step · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
