Steel flip-top fireplace (USFS LDFP6005)
2D drawing · DWF · 26 KB · by USDA Forest Service
Need another format? Open it in the viewer and use Export.
Public domain (US Government work). A work of the US federal government, in the public domain in the United States (17 U.S.C. §105). Free to use, modify and redistribute; rights outside the US may differ. About government works
Source: USDA Forest Service Engineering Drawing Library, plotted to DWF by Innerscene
Description
Plan, elevation, section and details of a campground fireplace. USDA Forest Service standard drawing plotted to a DWF sheet (ANSI B).
File: usfs-ldfp6005-steel-flip-top-fireplace.dwf · added 2026-10-24 · available until 2031-10-24. Added from USDA Forest Service Engineering Drawing Library, plotted to DWF by Innerscene under its public-domain status; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
