Worm reduction gearboxOpen in 3D

Worm reduction gearbox

3D model · STEP · 1.3 MB

Open in 3D viewerDownload STEP

Need another format? Open it in the viewer and use Export.

Public domain (CC0). Free to use, modify and redistribute for any purpose, including commercially, with no credit required. About CC0

Source: Innerscene - original model

Description

Worm reduction gearbox. Overall size 0.176 x 0.161 x 0.144 m; original unbranded model. Overall 176 x 161 x 144 mm. Nominal size: 176.00 x 161.00 x 144.00 mm overall. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.

MechanicalReal-world scaleCAD solidAssemblygearboxgear boxgear reducerdriveworm gearhelical gearboxtransmissionworm gearboxmechanical power transmissionindustrial driveoriginalcc0

File: worm-reduction-gearbox.step · added 2026-10-08 · available until 2031-10-08. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
