Three-pole MCCB 630 A frame with rotary handle
3D model · GLB · 681 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Three-pole MCCB 630 A frame with rotary handle. Overall 140.0 x 147.2 x 359.0 mm (width x depth x height, including handles, terminals and clips): three-pole moulded-case circuit breaker, 630 A frame, direct rotary handle shown ON with padlock hasp, Ir and Im setting dials, push-to-trip button, front copper terminal pads with M10 bolts and interphase barriers. Original unbranded model; printed ratings are generic, not a certification. Overall 140 x 147 x 359 mm. Nominal size: 140.00 x 147.20 x 359.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: three-pole-mccb-630-a-frame-with-rotary-handle.glb · added 2026-10-23 · available until 2031-10-23. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
