Four-channel 5 V relay module with optocouplers
3D model · GLB · 2.9 MB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Four-channel 5 V relay module with optocouplers. Overall 75.0 x 55.0 x 18.1 mm (X x Y x Z, Z up): blue board with four 5 V relays, four 3-way screw terminals, optocoupler inputs, TO-92 drivers, axial flyback diodes, channel LEDs, GND / IN1-IN4 / VCC header and a JD-VCC jumper. Original unbranded model; printed markings and ratings are generic, not a certification. Overall 75 x 55 x 18 mm. Nominal size: 75.00 x 55.00 x 18.10 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
