1-cell 18650 holder
3D model · STEP · 169 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
1-cell 18650 holder, modeled from published dimensions. Overall 22 x 76 x 16 mm. Key dimensions: cells 1; cell diameter clearance 19 mm; contact spacing nominal 67.6 mm. Cell envelope uses Molicel P28A maximum diameter 18.6 mm and height 65.2 mm. Terminal shapes and wrap are original simplified details; no manufacturer markings are copied. Holder and pack geometry are original nominal library designs. Series tabs illustrate alternating cell orientation. Protection, electrical insulation stack, wiring and enclosure integration are not an engineered battery system; this model makes no capacity or electrical performance claim. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
