SWR bridge board
2D drawing · CAD · 54 KB · by richardhosking
Need another format? Open it in the viewer and use Export.
Public domain (CC0). Free to use, modify and redistribute for any purpose, including commercially, with no credit required. About CC0
Source: richardhosking/PowerMeterKICAD on GitHub (CC0 1.0), exported to this format by Innerscene
Description
The directional coupler board of a radio power and SWR meter, with RF pads, detector diodes and a large ground area. Exported from the published KiCad board.
