Wooden surveyor tripod (flat head, 5/8 in screw)
3D model · GLB · 7.2 MB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Wooden surveyor tripod (flat head, 5/8 in screw). Overall 1036 x 898 x 1500 mm (X width x Y depth x Z height): wooden surveyor tripod at working height: lacquered hardwood split upper legs hinged on a 165 mm flat cast aluminium head with wing bolts, sliding lower legs with quick clamps, steel shoes with points and foot pegs, and the central 5/8 in x 11 fixing screw with its knob under the head. The head plate is 1490 mm above the floor and the tip of the fixing screw 1500 mm (the overall height). The leg points stand on a 1.12 m circle with one leg toward the back (+Y), so the footprint is 1036 mm across (X) and 898 mm deep (Y). Original unbranded model. Overall 1036 x 898 x 1500 mm. Nominal size: 1036.21 x 897.71 x 1500.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: wooden-surveyor-tripod-flat-head-5-8-in-screw.glb · added 2026-10-23 · available until 2030-10-23. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
