Sidewalk with curb
3D model · GLB · 3.8 MB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Sidewalk with curb: 12 m sidewalk band, 12.00 x 2.00 m footprint, 0.25 m overall height (measured, X x Y x Z), identical to the outer 2.00 m of the S12 street profile. Measured at both ends: 0.15 m precast curb whose face rises from road level (Z = 0) at Y = -1.00 m to +0.15 m, then 1.85 m of broom-finished concrete sidewalk at +0.15 m; base 0.10 m deep. Sidewalk joints about every 1.85 m (texture). Lines custom carriageways, parking areas or plazas. Original unbranded model. Overall 12 x 2 x 0.3 m. Nominal size: 12000.00 x 2000.00 x 250.00 mm overall. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: sidewalk-with-curb.glb · added 2026-10-24 · available until 2031-10-24. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
