Manual pallet jack
3D model · GLB · 96 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Manual pallet jack. Overall 730 x 1748.5 x 1340.5 mm. Key dimensions: fork length 1150 mm; fork width 160 mm; fork outer spacing 730 mm; lowered fork top 122.5 mm. Original manual pallet jack with fork tips, rollers, twin steering wheels, hydraulic pump and loop handle. Nominal visualization layout. Hydraulic linkages are simplified; load rating and lifting motion are not simulated. glTF binary (GLB) mesh with materials, modeled in meters at real-world scale. Export to other formats from the viewer. A nominal-scale visualization model, not manufacturer CAD. Original Innerscene model, released CC0.
File: pallet-jack-original.glb · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
