Elevator cabin, open doors
3D model · STEP · 197 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
Elevator cabin, open doors, modeled from published dimensions. Overall 1.8 x 1.6 x 2.4 m. Key dimensions: internal width 1700 mm; door clear width 1030 mm; ceiling omitted for review true. Original cabin layout with open doors and ceiling omitted for inspection. Shaft, drive, door mechanism and control circuitry are omitted. No accessibility, lift certification or code compliance is implied. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: elevator-cab.step · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
