700 mm track with three light heads
3D model · STEP · 132 KB
Need another format? Open it in the viewer and use Export.
Source: Innerscene - original model
Description
700 mm track with three light heads, modeled from published dimensions. Overall 700 x 68 x 175 mm. Key dimensions: track length 700 mm; track width 35 mm; head diameter 68 mm; head length 110 mm; head pitch 200 mm. Original unbranded three-head track assembly. Models physical fixture envelopes only; electrical contacts, adjustment locks and optical internals are omitted. No photometry or electrical rating. Exact solid STEP geometry in millimeters, opens in any CAD system. Export to STL, OBJ, GLB and other formats from the viewer. Nominal dimensions for layout, fit checks and visualization; they do not establish a manufacturing tolerance class, load rating or standards certification. Original Innerscene model, released CC0.
File: track-three-heads.step · added 2026-10-05 · available until 2031-10-05. Added from Innerscene - original model under its CC0 dedication; see the library terms. Think this part infringes someone’s rights? Use Report on the viewer page or see our copyright policy.
